Aruba 6300M 48-Port Gigabit Ethernet Managed Switch, 10/100/1000 Mbps, Black (JL663A)
$11,759.00
Per each
Aruba 6300M 48-Port Gigabit Ethernet Managed Switch, 10/100/1000 Mbps, Black (JL663A)
Item #:
369-IM16YE713
Model #:
JL663A
Brand:
Aruba
Not yet rated. Be the first to
Write a review!
Price drop
$11,759.00
Per each
Upgrade to get 5% off, earn points 10% faster and more. Annual fee of $49.99.
Aruba 6300M 48-Port Gigabit Ethernet Managed Switch, 10/100/1000 Mbps, Black (JL663A)
Limited quantity available: 2 remaining
Description
The Aruba CX 6300 Switch Series is a modern, flexible and intelligent family of stackable switches perfect for enterprise network access, aggregation, core and data center top of rack (ToR) deployments. Created for game- changing operational efficiency with built-in security and resiliency, the 6300 switches provide the foundation for high-performance networks supporting IoT, mobile and cloud applications. Built from the ground up with a combination of cutting-edge hardware, software and analytics and automation tools, the stackable 6300 switches are part of the Aruba CX switching portfolio, designed for today's enterprise campus, branch and data center networks. By combining a modern, fully programmable OS with the Aruba Network Analytics Engine, the 6300 switches provide industry leading monitoring and troubleshooting capabilities for the access layer. A powerful Aruba Gen7 ASIC architecture delivers performance and robust feature support with flexible programmability for tomorrow's applications. The Aruba Virtual Stacking Framework (VSF) allows for stacking of up to 10 switches, providing scale and simplified management. This flexible series has built-in wirespeed 1GbE/10GbE/25GbE uplinks. HPE Smart Rate multi-gigabit Ethernet paves the way for high speed access points and IoT devices. Aruba Dynamic Segmentation extends Aruba's foundational wireless role-based policy capability to Aruba wired switches. What this means is that the same security, user experience and simplified IT management can be enjoyed throughout the network. Regardless of how users and IoT devices connect, consistent policies are enforced across wired and wireless networks, keeping traffic secure and separate.
- Modern, flexible, and intelligent AOS-CX stackable switch perfect for enterprise access, aggregation, and ToR data center deployments
- This model has 48 x 10/100/1000 BASE-T ports and 4 x 1/10/25G SFP ports
- Manage via single pane of glass with Aruba Central across wired, wireless, and WAN
- Throughput: 369 Mpps maximum; switching capacity: 496Gbps
- Dimensions: 1.73"H x 17.4"W x 15.2"D
- Power consumption: hibernation (0 rpm fan): 9W, idle: 56W, 100% traffic rate: 75W
- Certifications and standards: Meets or exceeds the UL 60950-1 2nd Ed, FCC part 15 Class A standards
- Powered by quad-core ARM Cortex A72 1.8GHz, 8GB DDR4, 32GB eMMC, and 8MB packet buffer memory
- Equipped with 1 x USB Type-C console port, 1 x OOBM, 1 x USB Type-A host port, 1 x Bluetooth dongle to be used with CX mobile app
- Lifetime manufacturer limited warranty
Specifications
Brand
Aruba
Buffer Memory
8MB
Data Transfer Rate
10/100/1000 Mbps
Depth in Inches
15.2
Ethernet Number of Ports
31 to 50
Full-Duplex
Yes
Gaming
Non Gaming
Height in Inches
1.73
Input Voltage
100-240V
Jumbo Frame
9KB
LACP
Yes
Layer
3
Max. Data Transfer Rate (Mbps)
1000 - 1499
Network Management Type
Managed Switch
Number of Ethernet Ports
48
Performance Class
Gigabit Ethernet
Port Mirroring
Yes
Power Over Ethernet
No
Power Supply
Two field-replaceable, hot-swappable power supply slots
Quality of Service
Yes
Series or Collection
6300M
SNMP
v1, v2c, v3
Stackable
Stackable
Switch Form Factor
Rack Mountable
True Color
Black
VLAN Support
Yes
Warranty Information
Limited Lifetime Warranty
Weight (lbs.)
12.14
Width in Inches
17.4
